Rudra Tubefittings, located in Kolkata, India, specializes in crafting and supplying high-precision Bulkhead Union Elbows. These fittings are designed to create secure tube-to-tube connections through panels, walls, or bulkheads while allowing for a 90° directional change. They guarantee leak-proof performance in hydraulic, pneumatic, and instrumentation systems where safe passage through enclosures is crucial. Made from robust materials and precisely machined, Rudra’s Bulkhead Union Elbows maintain strong mechanical integrity even under high pressure, vibration, and continuous service conditions. Their durable construction, perfect alignment, and corrosion-resistant design make them a top choice for demanding industrial installations that require reliable and space-efficient routing.
Bulkhead Union Elbows are generally made from stainless steel (SS304/SS316), carbon steel, or alloy steel, depending on the specific pressure and corrosion requirements. These materials offer high tensile strength, excellent fatigue resistance, and durability when faced with vibration and pressure cycling. The fittings feature precision-machined bodies, ferrules, and nuts that ensure a tight metal-to-metal seal. Their mechanical properties include dimensional stability, strong wear resistance, and dependable performance across varying temperatures. With their rugged metallurgy, these fittings promise long-term leak-free service in both mild and harsh operating environments.
| Mcneil part no. | Equivalent Part no. Type 1 | Equivalent part no Type 2 | ODT-ØT(INCHES) | C | BODY HEX F | ODT-ØT1(INCHES) | Ø E | D | L | NUT HEX W | L1 |
| 1-BUD | -100-61 | 1BC1 | 1/16 | 0.43 | 5/16 | 1/16 | 0.05 | 0.34 | 0.84 | 5/16 | 1.24 |
| 2-BUD | -200-61 | 2BC2 | 1/8 | 0.60 | 7/16 | 1/8 | 0.09 | 0.50 | 1.50 | 7/16 | 2.02 |
| 3-BUD | -300-61 | 3BC3 | 3/16 | 0.63 | 9/16 | 3/16 | 0.12 | 0.54 | 1.59 | 7/16 | 2.11 |
| 4-BUD | -400-61 | 4BC4 | 1/4 | 0.70 | 5/8 | 1/4 | 0.19 | 0.60 | 1.03 | 9/16 | 2.27 |
| 5-BUD | -500-61 | 5BC5 | 5/16 | 0.73 | 11/16 | 5/16 | 0.25 | 0.64 | 1.81 | 5/8 | 2.39 |
| 6-BUD | -600-61 | 6BC6 | 3/8 | 0.76 | 3/4 | 3/8 | 0.28 | 0.66 | 1.87 | 11/16 | 2.45 |
| 8-BUD | -810-61 | 8BC8 | 1/2 | 0.86 | 7/8 | 1/2 | 0.41 | 0.90 | 2 | 7/8 | 2.80 |
| 10-BUD | -1010-61 | 10BC10 | 5/8 | 0.86 | 1-1/16 | 5/8 | 0.50 | 0.96 | 2.06 | 1 | 2.86 |
| 12-BUD | -1210-61 | 12BC12 | 3/4 | 0.86 | 1-3/16 | 3/4 | 0.63 | 0.96 | 2.31 | 1-1/8 | 3.11 |
| 14-BUD | -1410-61 | 14BC14 | 7/8 | 0.86 | 1-3/8 | 7/8 | 0.72 | 1.02 | 2.53 | 1-1/4 | 3.33 |
| 16-BUD | -1610-61 | 16BC16 | 1 | 1.04 | 1-5/8 | 1 | 0.88 | 1.23 | 2.81 | 1-1/2 | 3.77 |
At Rudra Tube Fittings, we are the leading supplier, manufacturer, and exporter of Bulkhead Union Elbow in Kolkata, Kolkata. Our state-of-the-art manufacturing facilities, strategically located in the Kolkata, empower us to provide high-quality solutions tailored to your specific requirements. With an extensive inventory of various premium materials, we are well-equipped to meet your needs efficiently. Our dedication to excellence and operational efficiency ensures we consistently maintain available stock, making us your trusted partner for reliable Union Cross fittings in various applications.
Rudra Tube Fittings is a leading supplier and stockist of premium Bulkhead Union Elbow in Kolkata, Kolkata. Our products are widely utilized across various industries, recognized for their strength, durability, and reliable performance in connecting multiple pipe sections. We are committed to delivering exceptional service and ensuring high levels of customer satisfaction. Our advanced manufacturing techniques set us apart in the fittings industry, enabling us to consistently provide top-quality Union Cross fittings while effectively addressing the unique requirements of our customers.
Contact us to get a quick quote for your requirement.
You’ll find Bulkhead Union Elbows in a variety of applications, including hydraulic machinery, instrumentation panels, pneumatic systems, chemical processing units, offshore equipment, and industrial control lines. They facilitate the passage of tubes through cabinets, tanks, or structural panels while changing direction by 90°, ensuring neat, safe, and organized piping layouts. These fittings are perfect for connecting pumps, valves, actuators, cylinders, transmitters, and distribution manifolds. Their ability to maintain a leak-tight seal under vibration and pressure makes them indispensable in many industrial settings.
