Rudra Tubefittings, located in Kolkata, India, stands out as a trusted manufacturer and supplier of Alloy 20 Tube Fittings, specifically designed for tough industrial settings that face high levels of corrosion. Renowned for its remarkable resistance to strong acids—particularly sulfuric acid—Alloy 20 excels where regular stainless steels fall short. Rudra’s fittings are expertly machined to ensure leak-proof, vibration-resistant connections in critical fluid and gas systems. Their Alloy 20 Tube Fittings promise a long service life, impressive mechanical strength, and reliable sealing even in harsh conditions. Industries rely on these fittings for consistent performance, chemical stability, and durability in challenging processing environments.
Alloy 20 Tube Fittings are crafted from a nickel-iron-chromium alloy, enhanced with molybdenum and copper, which provides outstanding resistance to sulfuric acid, chlorides, pitting, and crevice corrosion. The mechanical properties include high tensile strength, excellent ductility, and dependable toughness across a range of temperatures. Precision-machined ferrules, bodies, and nuts guarantee tight seals, stability under vibration, and the ability to withstand high pressure. Alloy 20 maintains its structural integrity in aggressive chemical environments, making these fittings perfect for severe service applications that demand long-lasting corrosion resistance and strong mechanical performance.
| Specifications | ASTM B366 / ASME SB366 |
|---|---|
| Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | Seamless Fittings: 1/2″ – 10″ Welded Fittings: 1/2″ – 48″ |
| Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| Manufacturing Standards | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011, DN15-DN1200 BS : BS4504, BS4504, BS1560, BS10 JIS : JIS B2311, JIS B2312, JIS B2313, JIS B2316 GOST : GOST 17375, GOST 17376, GOST 30753, GOST 17378, GOST 17379, GOST 17380 EN: EN10253-1, EN10253-2 |
| Types | Seamless / ERW / Welded / Fabricated |
| Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Elbow | Angle : 22.5 deg, 30deg, 45 deg, 90 deg, 180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D, 4D, 5D, 6D, 7D-40D. Standard: ASME B16.9, ASME B16.28, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO |
| Manufacturing process | Push, Press, Forge, Cast, etc. |
| Specialized manufacturer of | 90º Elbows, Couplings, Reducers, Inserts, Caps, Nipples, 45º Elbows, Tees, Crosses, Equal Tees & Reducing Tees |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
| Grade | C | Mn | Si | S | Cu | Ni | Cr | Fe | Mo | P |
|---|---|---|---|---|---|---|---|---|---|---|
| Alloy 20 | 0.07 max | 2.00 max | 1.00 max | 0.035 max | 3 – 4 | 32 – 38 | 19 – 21 | 29.85 min | 2.00 – 3.00 | 0.045 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.1 g/cm3 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 | Psi – 35,000, MPa – 241 | 30 % |
At Rudra Tube Fittings, we are the largest supplier, manufacturer, and exporter of Alloy 20 Tube Fittings in Kolkata, Kolkata. Our state-of-the-art manufacturing facilities, strategically located in the Kolkata, empower us to provide high-quality solutions tailored to your specific needs. With a comprehensive inventory exceeding 16,000 tons of premium materials, we are fully equipped to meet your requirements promptly. Our unwavering commitment to excellence and efficiency ensures that we consistently maintain stock availability to support your demands effectively.
| STANDARD | WERKSTOFF NR. | UNS | AFNOR | EN |
|---|---|---|---|---|
| Alloy 20 | 2.4660 | N08020 | Z2NCUD31-20AZ | NiCr20CuMo |
Contact us to get a quick quote for your requirement.
At Rudra Tube Fittings, we take pride in being the largest supplier, manufacturer, and exporter of Alloy 20 Tube Fittings in Kolkata, Kolkata. Our innovative solutions are designed to address all your piping requirements. With advanced production facilities strategically situated in the Kolkata, we maintain an extensive inventory of over 16,000 tons of high-quality materials, guaranteeing that we have the stock readily available to fulfill your needs efficiently.
Alloy 20 Tube Fittings find extensive use in industries that deal with corrosive fluids, acids, and environments rich in chlorides. They are particularly suited for chemical processing plants, sulfuric acid production facilities, pharmaceuticals, petrochemicals, food and beverage processing, pulp and paper mills, and dye or pigment manufacturing systems. These fittings ensure secure, leak-free connections in instrumentation lines, chemical transfer systems, sampling lines, and high-pressure pipelines. With their robust resistance to chemical attacks and excellent mechanical properties, they are a reliable choice for demanding applications.
Please feel free to contact us if you need any further information or for enquiry.
